Here are some Pictures and Info of Mr. Setzer's Guitars.

* For more info on Gretsch Guitars Visit The Gretsch website!

* For more info on TV Jones Pickups Visit the TV Jones website!

About Brian's Personal Gretsch Hotrods!!!

"Brian's Gretsches have Gibson Abr-1 Tune-O-Matic bridges fitted with

drilled-out aluminum saddles. It's a great setup.

The saddles move around freely in the Abr-1 design, which helps prevent

binding with the Bigsby, and the aluminum adds a nice ring and enhances resanance."

"Brian's Hotrods all have the new TV Jones Patent-Applied-For Filter 'Trons.

I gave one of my original '59 Filter 'Trons to Tom (a.k.a. TV Jones),

and he send it out to have the materials analyzed.

Now he's able to make exact replicas of Filter 'Trons with the

correct magnets and brass covers."

Setzer's Gretsches are superbly set up and sport beautiful fretwork,

courtesy of Jones, who installs the dunlop 6105 fret wire.

"Tom trims the fret height down a bit, and gives the frets a triangular crowning and nice,

bulbous ends".

"We use .010-.046 D'Addario string, and every other string change I touch-up

the saddles and nut slots with very fine emery cloth to eliminate burrs.

Then I finish off by putting a tiny amount of a graphite/oil mixture into the nut

and bridge slots. That helps a lot with a Bigsby, as do the locking Sperzel tuners,

which also improve the tone by adding mass to the headstock."

This is a Custom Painted Gretsch Setzer Hotrod.

Guitar - specifications -

* NECK:
- Laminated rock maple neck
- Rosewood fingerboard
- Neo-classical position markers
- 24-1/2" scale, 22 frets
- Adjustable truss rod
- Metal plate with "Setzer Hot Rod" name

* BODY:
- 16" wide, 2 1/2" deep
- Laminated maple
- Oversized f-holes
- Multiple binding
- Single cutaway

* ELECTRONICS:
- TV Jones Filtertron pickups
- Master volume control
- Pickup selector switch

* FEATURES:
- Chrome plated hardware
- Tune-O-Matic bridge with ebony base
- Vintage Gretsch V Bigsby vibrato tailpiece

Red, White & Black Hotrod!!

Another Custom Painted Gretsch Setzer Hotrod.

Brian had Gretsch send him a Setzer Hotrod painted Flat Black,

Then he Sent it to a Friend who painted it for him.

Guitar - specifications -

* NECK:
- Laminated rock maple neck
- Rosewood fingerboard
- Neo-classical position markers
- 24-1/2" scale, 22 frets
- Adjustable truss rod
- Metal plate with "Setzer Hot Rod" name

* BODY:
- 16" wide, 2 1/2" deep
- Laminated maple
- Oversized f-holes
- Multiple binding
- Single cutaway

* ELECTRONICS:
- TV Jones Filtertron pickups
- Master volume control
- Pickup selector switch

* FEATURES:
- Chrome plated hardware
- Tune-O-Matic bridge with ebony base
- Vintage Gretsch V Bigsby vibrato tailpiece

The Gretsch Hotrod!!

Brian's own version of a Gretsch 6120,

The Tangerine Hotrod guitar is painted  exactly like

Brian's 32 Ford Hotrod!!!

Guitar - specifications -

* NECK:
- Laminated rock maple neck
- Rosewood fingerboard
- Neo-classical position markers
- 24-1/2" scale, 22 frets
- Adjustable truss rod
- Metal plate with "Setzer Hot Rod" name

* BODY:
- 16" wide, 2 1/2" deep
- Laminated maple
- Oversized f-holes
- Multiple binding
- Single cutaway

* ELECTRONICS:
- TV Jones Filtertron pickups
- Master volume control
- Pickup selector switch

* FEATURES:
- Chrome plated hardware
- Tune-O-Matic bridge with ebony base
- Vintage Gretsch V Bigsby vibrato tailpiece

* COLORS:
- Metallic Blue
- Metallic Purple
- Metallic Tangerine
- Metallic Candy Red

DoubleNeck Dano!!

A customized Danelectro Doubleneck Bass/Guitar

This Guitar Is truely one-of-a kind!!

Look for this Guitar when Brian uses it on tour when

he plays 5years, 4months, 3days.

Guitar - specifications -

* NECK:
- Laminated hard maple neck (guitar and bass)
- Rosewood fingerboard (guitar and bass)
- dot inlay position markers (guitar and bass)
- scale, 22 frets (guitar)
- scale, 25 frets (bass)

* ELECTRONICS:
- two single-coil lipstick pickups (guitar)

- Original style brass tube w/crome plating magnet - Original

  formula 50's style Alnico magnet. (bass)

- Volume and tone for each pickup

* FEATURES:
- Chrome plated hardware
- Double neck 4/6 Strings

- Coustom Blue Sparkle Paint Job

The Arsenal!!

Photos from BrianSetzer.com

Brian Setzer's Strings

Brian Setzer uses these type of Strings on his Gretsch Guitars!!!

* D'Addario EXL110 Electric Guitar Strings

* D'Addario ECG24 Chromes Electric Guitar Strings

* D'Addario ECG25 Chromes Electric Guitar Strings
